Crane / TLS / TLSM Torque Transducers

The TLS and TLSM torque transducers provide accurate torque measurement at speeds of up to 15,000 rpm. These transducers have a contactless and digital signal transmission from rotor to stator for complete and accurate torque measurement. It is therefore highly accurate and maintenance-free.

The range has integral signal conditioning providing a ±5V analogue output, with an option for+/-10V. Optional speed and angle measurement is also available for sizes up to 1000Nm; this is a 2 x 360 TTL pulses/rev offset by 90°. For sizes above this, the option for speed is 60 pulses/rev.

Available in a range of sizes from 0.1Nm to 20,000Nm
Optional integrated speed/angle measurement
Accuracy Class 0.1%
Optional Accuracy Class 0.2%
Full scale analogue output 0±5V (optional ±10V)
Span Shift <±0.01%/°C
Operating Temp 0 to +60°C
Zero Shift < ±0.01%/°C
Overload Capacity 150% fs
