General test and measurement as well as machine monitoring and control. Ideal for packaging machinery, assembly machinery or end-of-line test equipment.
Dimension:
Technical Data:
Capacity
1/2/5/10/20/50kg
Material
Aluminum
Rated output
1kg 1.0mV/V ; 2-20kg 2.0mV/V
Non-linearity
±0.05 % F.S.
Output Impedance
350±5Ω
Hysteresis
±0.05% F.S.
Insulation
>5000MΩ/10VDC
Repeatability
±0.03% F.S.
Recommended Excitation
2.5-5V
Creep(30min)
±0.03% F.S.
Excitation max
10V
Temp Effect On Output
0.05 % F.S./ 10℃
Compensated Temp Range
-10~60℃
Temp Effect On Zero
0.05% F.S./ 10℃
Operating Temp Range
-20~80℃
Protection Class
IP 65
Safe Load
1.2
Input Impedance
385±50Ω
Ultimate Load Limit
1.5
Product name
LC2418 Factory Tension Load Cells Micro S Load Cell
Brand
SAINTBOND
Market
All over the world
Features
High precision and stable performance
Advantage
0EM/ODM
Sample Lead Time
5~ 40Days
Sample price
The price is different according to product capacity
