SAINTBOND / LC398 500kg 1000kg 50 Ton Shelf Load Weight Sensor Shear Beam Load Cell
LC398 500kg 1000kg 50 Ton Shelf Load Weight Sensor Shear Beam Load Cell
Product Description
Dimension:
Key Features:
◎Alloy /Stainless steel construction;
◎Hermetically sealed;
◎Wide capacity range;
◎High accuracy;
Application:
Bagging machinery, conveyor scales, vessel and hopper weighing systems.
Technical Parameter:
| Rated Load: |
5/10/15/18klbs |
| Sensitivity: |
(2.0±0.1%) mV/V |
Operating Temp. Range: |
-10~+70℃ |
| Combined Error: |
±0.02% F.S |
Maximum Safe Over Load: |
150%F.S |
| Creep Error(30min): |
±0.03% F.S |
Ultimate Over Load:: |
300%F.S |
| Zero Balance: |
±1% F.S |
Recommend Excitation Vol.: |
10~12V DC |
| Temp. Effect On Zero: |
±0.02% F.S/10℃ |
Maximum Excitation Vol.: |
15V DC |
| Temp. Effect On Span: |
±0.02% F.S/10℃ |
Sealing Class: |
IP68 |
| Input Resistance: |
385±5Ω |
Element Material: |
Alloy Steel, Stainless Steel |
| Output Resistance: |
351±2Ω |
Cable: |
Length=L:3m |
| Insulation Resistance: |
≥5000MΩ |
Citation: |
GB/T7551-2008/OIMLR60 |
| Product name |
LC398 500kg 1000kg 50 Ton Shelf Load Weight Sensor Shear Beam Load Cell |
| Brand |
SAINTBOND |
| Market |
All over the world |
| Features |
High precision and stable performance |
| Advantage |
0EM/ODM |
| Sample Lead Time |
5~ 40Days |
| Sample price |
The price is different according to product capacity |
| Custom Design |
Welcome |
| Form of sale |
Factory supply |
