TK Three-Roller Online Precise Measurement Tension Sensor Tension Detector
Features
-
Measuring capacity (kg): 100 ~ 1000
-
Measurement method: Resistive strain gauge
-
Structure: Compact, highly durable, and easy to install
-
Performance: High overall accuracy and stability
-
Material: High-quality nickel-plated alloy steel
-
Roller material: Alloy steel
-
Output: Compatible with amplifiers — supports 0–10 V or 4–20 mA output
-
Function: Enables accurate real-time tension measurement online
-
Applications:
-
Online rope tension measurement
-
Continuous online tension monitoring for products such as fibers, wires, and metal strands
-
Dimensions
Specifications
Specifications: | ||
Rated Load | kg | 100,200,300,500,1000 |
Rated Output | mV/V | 1.5 |
Zero Balance | %R.O. | ±1 |
Comprehensive Error | %R.O. | ±0.3 |
Compensated Temp.Range | ℃ | -10~+40 |
Operating Temp.Range | ℃ | -20~+70 |
Temp.effect/10℃ on output | %R.O./10℃ | ±0.05 |
Temp.effect/10℃ on zero | %R.O./10℃ | ±0.05 |
Recommended Excitation Voltage | VDC | 5-12 |
Maximum Excitation Voltage | VDC | 5 |
Output impedance | Ω | 350±5 |
Input impedance | Ω | 380±10 |
Insulation resistance | MΩ | =5000(50VDC) |
Safe Overload | %R.C. | 150 |
Ultimate Overload | %R.C. | 300 |
Material | Alloy Steel | |
Degree of protection | IP65 | |
The length of the cable | m | 3m |
※ Product specifications are subject to change without notice.
