VALCOM / VLC-G471M2 Environment-Poof Button Load Cell

VLC-G471M2 Environment-Poof Button Load Cell

Rated output	1.5mV/V±2%
Nonlinearity	±0.1%R.C.
Hysteresis	±0.1%R.C.
Repeatability	±0.1%R.C.
Zero balance	±5%R.O.
Temperature effect on zero balance	±0.05%R.C./10°C
Temperature effect on load	±0.05%R.C./10°C
Safe overload rating	200%R.C.
Temperature compensation range	−10–60°C (No condensation or freezing)
Safe temperature range	−15–75°C (No condensation or freezing)
Input terminal resistance	350Ω±2%
Output terminal resistance	350Ω±2%
Recommended excitation voltage	1~10V
Safe excitation voltage	15V
Insulation resistance	1000MΩ or more
IP rating	Equivalent to IP65 (Note 1)
Cable	φ8-4-core Shielded cable (CESV-B) 10m Non-stranded wire

(Note 1) Sealing performance of the cable outlet may deteriorate due to the change of cable jacket over years.

Model	Rated capacity	Deflection at R.C.	Weight
VLC-2KNG471M2	2kN	0.09mm	Approx. 3.3kg
VLC-5KNG471M2	5kN	0.05mm
VLC-10KNG471M2	10kN	0.04mm
VLC-20KNG471M2	20kN	0.03mm
VLC-50KNG471M2	50kN	0.02mm
