VALCOM / VLC-G811 Flat type Load Cell

VLC-G811 Flat type Load Cell

Rated output	0.990–1.010mV/V
Nonlinearity	±0.5%R.C.
Hysteresis	±0.5%R.C.
Repeatability	±0.3%R.C.
Zero balance	−0.050–0.050mV/V
Temperature effect on zero balance	±0.1%R.C./10°C
Temperature effect on load	±0.1%R.C./10°C
Safe overload rating	150%R.C.
Temperature compensation range	−5–70°C (No condensation or freezing)
Safe temperature range	−10–75°C (No condensation or freezing)
Input terminal resistance	343.0–357.0Ω
Output terminal resistance	343.0–357.0Ω
Recommended excitation voltage	8V or less
Maximum excitation voltage	12V
Insulation resistance	1000MΩ or more(DC 50V)
IP rating	Equivalent to IP50 (Note 1)
Cable	φ6mm 4-core shielded robot cable (KDF-SB) 5m, directly-connected

(Note 1) Sealing performance of the cable outlet may deteriorate due to the change of cable jacket over years.

Model	Rated capacity	Deflection at R.C.	Weight
VLC-10KNG811	10kN	Approx. 0.04mm	Approx. 700g
VLC-20KNG811	20kN
VLC-50KNG811	50kN
