VALCOM / VRTNC3 series Load button type load cell

VRTNC3 series Load button type load cell

Rated output	2.85mV/V±10%
Nonlinearity	±0.02%R.C.
Hysteresis	±0.02%R.C.
Temperature effect on zero balance	±0.007%R.C./10°C
Temperature effect on load	±0.008%R.C./10°C
Safe overload rating	Approx. 170%R.C. (330t;470t:Approx. 150%R.C.)
Permissible Dyn. Load	70% of rated capacity (Allowable oscillation amplitude as per DIN 50100)
Permissible Static Side Load	0.5 (But, Maximum permissible static side load = 0.3max or less)
Temperature compensation range	−10–40°C (No condensation or freezing)
Safe temperature range	−30–80°C (No condensation or freezing)
Input terminal resistance	4350.0–4550.0Ω
Output terminal resistance	4009.5–4010.5Ω
Recommended excitation voltage	5V
Excitation voltage range	5–30V (Max. 60V)
Insulation resistance	2GΩ
IP Rating	Equivalent to IP68 (Note 1)
Cable	φ6.5mm 4-core Shielded cable See dimension L in table below.

Creep 30min: 0.017%R.C.
(Note 1) Sealing performance of the cable outlet may deteriorate due to the change of cable jacket over years.

Model	Rated capacity	Deflection at R.C.	φA	φB	φC	H	J	K	L	Weight
VRTNC3-1t	1ton(9.807kN)	0.13mm	49	20	60	43	–	7.5	5m	Approx. 0.6kg
VRTNC3-2.2t	2.2ton (21.57kN)	0.12mm	49	20	60	43	–	7.5	5m	Approx. 0.6kg
VRTNC3-4.7t	4.7ton (46.09kN)	0.12mm	49	20	60	43	–	7.5	5m	Approx. 0.7kg
VRTNC3-10t	10ton (98.07kN)	0.17mm	74	30	75	50	7	6.5	5m	Approx. 1.2kg
VRTNC3-15t	15ton (147.1kN)	0.18mm	75	30	75	50	7	6.5	5m	Approx. 1.3kg
VRTNC3-22t	22ton (215.7kN)	0.21mm	75	30	75	50	7	6.5	12m	Approx. 1.3kg
VRTNC3-33t	33ton (323.6kN)	0.25mm	95	40	95	65	7	10	12m	Approx. 2.1kg
VRTNC3-47t	47ton (460.9kN)	0.33mm	130	60	130	75	7	14	12m	Approx. 4.3kg
VRTNC3-68t	68ton (666.9kN)	0.35mm	130	60	130	85	7	14	12m	Approx. 4.8kg
VRTNC3-100t	100ton (980.7kN)	0.45mm	150	70	150	90	7	16	12m	Approx. 7.0kg
VRTNC3-150t	150ton (1.471MN)	0.57mm	150	70	150	100	7	16	5m	Approx. 8.6kg
VRTNC3-220t	220ton (2.157MN)	0.67mm	225	100	225	130	10	24	5m	Approx. 22kg
VRTNC3-330t	330ton (3.236MN)	0.85mm	225	100	225	145	10	24	5m	Approx. 29kg
VRTNC3-470t	470ton (4.609MN)	1.00mm	270	120	270	170	10	28	5m	Approx. 50kg
