VALCOM / VZ6FC3 Beam Load Cell

VZ6FC3 Beam Load Cell

Rated output	1.999–2.001mV/V
Nonlinearity	±0.0180%R.C.
Hysteresis	±0.0170%R.C.
Zero balance	±0.020mV/V
Temperature effect on zero balance	±0.0125%R.C./10°C
Temperature effect on load	±0.0080%R.C./10°C
Safe overload rating	150%R.C.
Temperature compensation range	−10–40°C (No condensation or freezing)
Safe temperature range	−30–70°C (No condensation or freezing)
Input terminal resistance	350.0–480.0Ω
Output terminal resistance	355.8–356.2Ω
Recommended excitation voltage	5V
Excitation voltage range	0.5–12V
Insulation resistance	5GΩ
IP	Equivalent to IP68 (Note 1)
Cable	φ5.4mm 6-core Shielded cable 3m

Creep 30min: ±0.083%R.C.
(Note 1) Sealing performance of the cable outlet may deteriorate due to the change of cable jacket over years.

Model	Rated capacity	Deflection at R.C.	Weight
VZ6FC3-10kg	10kg (98.07N)	0.3mm	Approx. 0.5kg
VZ6FC3-20kg	20kg (196.1N)	0.29mm
VZ6FC3-50kg	50kg (490.3N)	0.27mm
VZ6FC3-100kg	100kg (980.7N)	0.31mm
VZ6FC3-200kg	200kg (1.961kN))	0.39mm
VZ6FC3-500kg	500kg (4.903kN)	0.6mm
VZ6FC3-1t	1ton (9.807kN)	0.55mm	Approx. 2.3kg
