VALCOM / VZ6FC6 Extremely High Accurate Beam Load Cell

VZ6FC6 Extremely High Accurate Beam Load Cell

Rated output	2mV/V±0.05%
Nonlinearity	±0.0110%R.C.
Hysteresis	±0.0080%R.C.
Zero balance	−0.020–0.020mV/V
Temperature effect on zero balance	±0.0093%R.C./10°C
Temperature effect on load	±0.0040%R.C./10°C
Safe overload rating	150%R.C.
Temperature compensation range	−10–40°C (No condensation or freezing)
Safe temperature range	−30–70°C (No condensation or freezing)
Input terminal resistance	350.0–480.0Ω
Output terminal resistance	356±0.12Ω
Recommended excitation voltage	5V
Excitation voltage range	0.5–12V
Insulation resistance	5000MΩ
IP rating	Equivalent to IP68 (Note 1)
Cable	φ5.4mm 6-core Shielded cable 3m

Creep 30min:±0.083%R.C.
(Note 1) Sealing performance of the cable outlet may deteriorate due to the change of cable jacket over years.

Model	Rated capacity	Deflection at R.C.	Weight
VZ6FC6-50kg	50kg (490.3N)	Approx. 0.27mm	Approx. 0.5kg
VZ6FC6-100kg	100kg (980.7N)	Approx. 0.31mm
VZ6FC6-200kg	200kg (1.961kN)	Approx. 0.39mm
