LC521B series storage tank with special weighing sensor has the advantages of high response speed, reasonable structure, characteristics of anti eccentric load ability, simple installation is a patent product of our company; the water storage tank weighing sensor products applicable in a variety of harsh industrial environment and has long-term stability; specifically for storage tank, storage tank, storage tank and other equipment quantity body design.
Dimension:
Technical Parameter:
Rated Load:
5/10/15/20t
Safe Overload:
150%F.S
Rated Output:
2.0000±0.001MV/V
Ultimate Overload:
200%F.S
Total Error:
±0.1%F.S
Operating Temp.Range:
(-30～+70)℃
Creep(30minutes):
±0.02%F.S
Compensated Temp.Range:
(-20～+60)℃
Insulation Impedance:
≥5000MΩ
Temperature Effect On Load:
±0.02%F.S/10℃
Max. Excitation Vol.:
15V(AC or DC)
Temperature Effect On Zero:
±0.02%F.S/10℃
Zero Balance:
±1%F.S
Material:
Alloy Steel
Input Impedance:
380±5Ω
Protection Class:
IP68&IP67
Output Impedance:
350±2Ω
Citation:
GB/T7551-2008
Recommended Excitation Vol.:
5V～12V(AC or DC)
Recommended Excitation Vol.:
5V~12V(AC or DC)
Product name
LC521B Spoke Web Type Load Cells Weight Sensor Spoke Type
Brand
SAINTBOND
Market
All over the world
Features
High precision and stable performance
Advantage
0EM/ODM
Sample Lead Time
5~ 40Days
Sample price
The price is different according to product capacity
